Log Collecting with ELK and Rsyslog.

Recently, we faced the problem of collecting logs from six main and spare servers with a lot of running applications. Every application generates about 8,000 logs per hour. Also, we will soon need to be collecting logs from ~120 Windows machines. At the moment, there are a large number of ready-made solutions that did not meet our requirements. In the end, we chose the simplest and at the same time elegant solution in the form of a collector and a repository of logs —ELK(Elasticsearch, Logstash, Kibana) stack, and as a sender — Rsyslog.

Now let’s take it one after another:

The problem and the solution:

We have 3 main and 3 spare servers with a lot of launched applications. Every application writes logs in the JSON-strings format into Syslog. In the near future, we will need to collect logs from a lot of Windows machines, but this is a completely different story.

The schematic solution looks like this:

Log Collecting with ELK and Rsyslog.

Looks good and scalable. Let’s go to preparing and configuring.

Prepare ELK:

Because we love Docker, we will use it! And for our convenience, we will use docker-compose.

Docker-compose file:

version: '3.2'

services:
elasticsearch:
image: docker.elastic.co/elasticsearch/elasticsearch:7.10.0
volumes:
- type: bind
source: ./elasticsearch/elasticsearch.yml
target: /usr/share/elasticsearch/config/elasticsearch.yml
read_only: true
- type: volume
source: elasticsearch
target: /usr/share/elasticsearch/data
environment:
ES_JAVA_OPTS: "-Xmx512m -Xms512m"
discovery.type: single-node
ports:
- "9200:9200"
- "9300:9300"
networks:
- elk

logstash:
image: docker.elastic.co/logstash/logstash:7.10.0
volumes:
- type: bind
source: ./logstash/config/logstash.yml
target: /usr/share/logstash/config/logstash.yml
read_only: true
- type: bind
source: ./logstash/pipeline
target: /usr/share/logstash/pipeline
read_only: true
ports:
- "5000:5000/udp"
- "9600:9600"
environment:
LS_JAVA_OPTS: "-Xmx512m -Xms512m"
networks:
- elk
depends_on:
- elasticsearch

kibana:
image: docker.elastic.co/kibana/kibana:7.10.0
volumes:
- type: bind
source: ./kibana/kibana.yml
target: /usr/share/kibana/config/kibana.yml
read_only: true
ports:
- "5601:5601"
networks:
- elk
depends_on:
- elasticsearch

networks:
elk:
driver: bridge

volumes:
elasticsearch:

We don’t use scaling, because for now, one node is enough. But in the future, we will have to think about scaling.

Elasticsearch configs:

cluster.name: "docker-cluster"
network.host: 0.0.0.0

# X-Pack settings
xpack.license.self_generated.type: basic
xpack.security.enabled: true
xpack.monitoring.collection.enabled: true

Kibana configs:

server.name: kibana
server.host: "0"

# X-Pack settings
xpack.monitoring.ui.container.elasticsearch.enabled: true

# Elasticsearch settings
elasticsearch.hosts: [ "http://elasticsearch:9200" ]
elasticsearch.username: elastic
elasticsearch.password: strongpassword

Logstash configs:

http.host: "0.0.0.0"

# X-Pack settings
xpack.monitoring.elasticsearch.hosts: [ "http://elasticsearch:9200" ]
xpack.monitoring.enabled: true
xpack.monitoring.elasticsearch.username: elastic
xpack.monitoring.elasticsearch.password: strongpassword

Logstash pipeline configs:

input {
udp {
port => 5000
codec => "json"
type => "rsyslog"
}
}

filter {
json {
source => "message"
skip_on_invalid_json => true
}
}

output {
elasticsearch {
index => "syslogs-%{+YYYY.MM}"
hosts => "elasticsearch:9200"
user => "elasticuser"
password => "strongpassword"
}
}

After all, we can just run our stack.

docker-compose up -d

After all, containers are started, you can go to the address 127.0.0.1:5601 and if everything is done correctly, we get into the Kibana web interface.

Prepare Rsyslog on servers:

First of all, we need to make sure that all the logs from the applications fall into Syslog.

Go to /etc/rsyslog.d/ and create two files:

  1. File “01-json-template.conf”

I will prepare a template for outgoing data. Let’s deal with the structure. The first value its timestamp for future filtering. Further, messages from the application converted into JSON format. The next value is sysloghost; it’s the name of the server host machine: we need it because, in the future, we will need to separate the logs from different servers. And the last value is programname; it’s the name of the application that has written the log.

template(name="json-template" type="list") {
constant(value="{")
constant(value="\"@timestamp\":\"") property(name="timereported" dateFormat="rfc3339")
constant(value="\",\"message\":\"") property(name="msg" format="json")
constant(value="\",\"sysloghost\":\"") property(name="hostname")
constant(value="\",\"programname\":\"") property(name="programname")
constant(value="\"}\n")
}

2. File “60-output.conf”

if $programname == [“app1”,”app2”,”app3”] then  @elk-server-api:5000;json-template

*Array matching working only in rsyslog ≥ 7.2

Go to Kibana

First, to configure Kibana, go into Management/Index Patterns and create Pattern syslogs-*. After this, Kibana will find all our log indexes.

In the Kibana Discover page, we can use Kibana Query Language(KQL) for selecting and filtering logs. Examples:

  • Get logs only from “Server2”:

sysloghost : “Server1”

  • Get “App2” logs from “Server1”

sysloghost : “Server1” and programname : “App2”

  • Filter by level:

sysloghost : “Server1” and programname : “App2” and level : “info”

P.S. Don’t forget to configure your Index Lifecycle Policies (ILM).

Our example of the Index Lifecycle Policies:

The Example of the Index Lifecycle Policies.
Index Lifecycle Policies.

That’s all. For more convenient log monitoring, we have set up the simple Kibana Dashboard. It looks like this:

Kibana Dashboard.

Conclusion

To be collecting logs from different servers and services, we can use a simple solution with rsyslog and ELK. As a result, we get a fast, flexible, and scalable system to monitor and find the logs we need.
